Compact your backup space
The script should compact your
backup space on our backup server but leave all your current files
definitely untouched. It is thus very secure and nothing can happen,
except that the script would not start. It is also unproblematic to
interrupt the script while it is running. In effect, the script should
reduce the amount of space occupied by some files you deleted
a while ago. If you are confident that you did not remove sets
of files by accident in the past, please feel free to start the script via
- /home/polyphys/backup_cleanup
at any time, and especially, when lamps are becoming yellow or red.
Print Polymer Physics A0 Poster
-
FAX@ETH online (level 1)
Send fax under unix
- vpp -destination="FAXNUMBER@fax" -device=pts -form=a4 -note="TONAME" FILE.PS
with
- TONAME : Name of recipient
- FAXNUMBER : Fax number (without the leading 0, e.g. HCO: 6321076, Germany: 0049xxxxxx)
- FILE.PS : A postscript file to send (max. 10 pages)
Priting under unix
login to matl-s19
lp -d P -o duplex filename
where P is polyphys-p02, polyphys-p03, polyphys-p08, or polyphys-p10
Print colored transparencies for presentations
- vpp -destination=hilspez -device=x8200 -form=a4.folie FILE.PS
with
- FILE.PS : One or more (e.g. FILE*.PS) postscript files
Print colored on white paper
- vpp -destination=rzspez -device=CLC1150 -form=a4 FILE.PS
with
- FILE.PS : One or more (e.g. FILE*.PS) postscript files
Line numbering in LaTeX
You need lineno.sty and then do the following:
[1] change document class to
\documentclass[12pt]{article}
(but should also work with other classes, just try)
[2] insert
\usepackage{lineno}
[3] after \begin{document} insert
\linenumbers
[4] each occurrecnce of \begin{eqnarray} and \begin{equation} must be
preceeded by an empty line
EMO-Manual
- Medium (1.2GB) ins EMO-Laufwerk einlegen (nene,skua oder tody).
- EMO mounten:
/usr/programs/scripts/mount_mo
- Eventuell: Formatieren eines neuen EMO-Mediums:
/usr/programs/scripts/MO_init
- Persoenliches directory auf EMO-Platte erstellen:
/usr/programs/scripts/mkdir ~/MO/mydirname
- Daten aus directory >Data< auf die EMO-Platte kopieren:
/usr/programs/scripts/cp -r Data ~/MO/mydirname
- Nach der Benutzung: EMO-Laufwerk freigeben!
/usr/programs/scripts/umount_mo
scp in batch mode
serverA)
cd .ssh;
ssh-keygen -d [defaults + no pass phrase]
chmod 600 id_dsa.pub;
scp id_dsa.pub user@serverB:~/.ssh/new
serverB)
cd .ssh;
cat new >> authorized_keys2; [create if not existing]
chmod 600 authorized_keys2; [important]
serverA)
scp id_dsa.pub user@serverB:~/dummy [works without password prompt, or scp -B ...]
ssh user@serverB ['commands'] [works without password prompt]
from within job script
$back=`pwd`; chomp $back;
# print `rsh gonzales2-c '(cd $back/$workingdir; /usr/bin/scp *.eps username\\\@polychem.ethz.ch-s0x:)';`;
print `ssh user@bru-tus-IP "cd $back/$workingdir; /usr/bin/scp *.eps username\@polychem.ethz.ch-s0x:";`;
Scanner at HCI H 540 (PC turbot)
The scanner has the possibility to scan papers and slides.
To scan slides, remove the white cover inside of the main cover.
There is a frame to insert the slides.
Start the scan process from Adobe Photoshop, OmniPage Pro 14 (OCR scan software) or HP Director.
A small HP handout is by the scanner.
Please change the default "save picture settings"
start the program HP Director
utilities - hp director - settings - save picture settings - save settings - save to
browse and select
My Documents\My Pictures
- For image processing start the program "Photoshop" than select
- file - import - twain_32 -
- For text processing start the program "OmniPage Pro"
Postscript under WNT
(Vielen Dank an Harald für die folgende Beschreibung vom 5.6.2001)
Gleich in welcher Applikation man ein ps-file erzeugen will,
der Vorgang ist derselbe:
- file - print - print to file -> set working path and file name
- file - print - setup -> set the right printer driver (e.g. Fiery CLC 700/800)
- file - print - setup - properties -> check settings about the "new" printer driver
Die noetigen Informationen ueber den richtigen printer driver (Fiery,
Pictro, etc),
welches Format etc. erhaelt man unter der home page von vpp:
hier, oder
hier .
DLT-Laufwerk at ML J 27 (petrel)
(Vielen Dank an Caroline für die folgende Beschreibung vom 27.2.2000)
- Vorbereitungen
- Wenn nötig "Write Protection" aufheben, indem der Schieber beim Band
nach rechts geschoben wird (Vgl. Anleitung)
- Untere Klappe hochheben und Band oben einschieben,
dann untere Klappe wieder senken.
"Tape in Use" muss nun konstant leuchten, ansonsten allenfalls
das Band nochmals herausnehmen und wieder einschieben!
- Density Select: gewünschte Komprimierung wählen
- Backupbefehl
- Um ein Backup des gesamten Home Directory's zu machen:
cd $HOME;
tar cvf /dev/rmt/0 . (Der Punkt gehört zum Kommando).
- oder als Batchjob (inkl. Angabe über die Grösse
des Homes und der benötigten Zeit):
cd $HOME;
batch << !
du -sk
timex tar cvf /dev/rmt/0 .
!
- Kontrolle
- Um zu überprüfen, was alles auf das Band geschrieben wurde:
tar xvf /dev/rmt/0
- Tapes
Es gibt Tapes mit verschiedenen Kapazitäten:
- Typ III: 10-20 GByte, Kosten ca. 50-60 Sfr pro Band
- Typ IV : 20-40 GByte, Kosten ca. 100-120 Sfr pro Band
-
Fortran check for NaN
a = asin(1.1); if (a.ne.a) print *, 'is NaN'
WCMS
- ETH instructions
- infrae 1.4 (ETH at 1.1.5)
- ETH Testserver
- mat (no login)
- 4 partitions (OS,1.Instanz silva-zope,copy,2.Instanz)
- add /edit or /manage to webaddresses
- cgi via zope
- perl -> MYSQL
- latex+variables -> marc
- static addresses everywhere
- auto: date, author, impressum
- compatible with htaccess syntax ? (if not, complain)
Netbackup
gonzales
asgard cluster
polphy cluster
- Information on batch system: call >c -help<
- Resolve problem with shared libraries: add "-non_shared" to the linker option
- PVM is installed: further information
Other computing resources at ETH
-
Proper eps-files generated by powerpoint
Print on file by selecting the polyphys-p03 printer. Then
view the ps-file via ghostview, and convert to eps. This
file is ideally suited to be used by latex.
-
Remarks on the Generation of PDF Files:
in case the sepp-version ps2pdf (or dvi2pdf) fails.
Authors using LaTeX2e need to run dvips to generate a
Postscript version of their file. PDF files can be generated by
applying software tools based on the Ghostscript package (http://www.cs.wisc.edu/~ghost/).
These are e.g. dvipdf for PDF file generation directly
from the .dvi file, or ps2pdf, which allows a file
conversion from Postscript to PDF format. On-line distiller
programs based on the Ghostscript package do also exist, see e.g.
http://www.ps2pdf.com/ for an
on-line version of ps2pdf based on the current Ghostscript
package AFPL Ghostscript 6.50.
Postscript file generation from MSWord is done by first
selecting a Postscript printer, and then make a
``Print to File''. For PDF file generation, again a distiller
program like ps2pdf may be applied. In order to directly
generate PDF files from Windows / Macintosh programs, one of the
(commercially available) Adobe Acrobat Toolkits, Acrobat Distiller
or PDFWriter may be used.
